Author Topic: Jet Ski Information History of the Jet Ski - stand-up watercraft  (Read 31240 times)

Offline Nigel

Jet Ski Information History of the Jet Ski - stand-up watercraft
« on: March 05, 2014, 08:23:19 PM »

Kawasaki introduced Jet Skis WSAA and WSAB in 1973, the first ever stand-up watercrafts which were limited in production before the company from Akashi decided to bring them in to mass production in 1976.

There are not many out there in the international personal watercraft scene or jet skiing as it used to be in past that know many things about the history of this sport. Actually, many people including enthusiasts of the sport or even Kawasaki CEO’s in many countries who believe that Kawasaki invented the Stand-Up watercraft. Well, they are wrong since there is only one guy in the world who had this vision and drew it on paper and patent it before actually signing an agreement with Kawasaki to produce the first Stand-Up. It was Clayton Jacobson II, an ex banker from Arizona who started working on this project –the project of personal watercraft- in 1960.

On August 15, 1971, Clayton Jacobson’s agreement with Bombardier had expired and it was that very day that Kawasaki signed an agreement to license Jacobson’s invention. By this time, Jacobson had already built his seventh prototype stand-up personal watercraft, using a 372ccRotax water-cooled engine that was in the 1969 model Sea-Doo. However according to Jacobson, Kawasaki was much more receptive and gave him everything he wanted, including corrosion-resistant materials and a 40hp, 400cc, water-cooled engine. The original engine Kawasaki gave Jacobson was a prototype snowmobile engine and it ended up becoming the foundation for 440cc Jet Ski engine.

When Kawasaki manufactured the very first production stand-up personal watercraft, the term or logo of Jet Ski was not yet in use. Originally it was referred as a “Water Jet” on service manuals and later on as “Power Skis” in the owner’s manual.

Jacobson and Kawasaki created six-to-seven different prototypes in 1972, before bringing two models to the market in 1973, the WSAA and the WSAB. The two original models were made of hand-laid fiberglass and included the 1973 WSAA Jet Ski 400, and the WSAB Jet Ski 400. The WSAA featured a flat bottom design that stayed with the JS hull until 1994. The WSAB featured a V-hull that enhanced turning, but was less stable and harder to ride. Approximately 550 of these, WSAA and WSAB, Jet Skies were ever produced, a third of them with the V hull and the other two-thirds with the flatter WSAA hull.

Fred Tunstall, a long time Kawasaki employee had mentioned in the past that they worked on a half-dozen different prototypes in 1972 before eventually deciding on the two models that would hit the market a year later (1973), the WSAA and WSAB. WSAA featured a hull similar to the one installed later on the JS400 and JS550 models. On the other hand WSAB used an aggressive, deeper-V hull. Kawasaki had worked on a lot of different things back in those days but there are probably about six prototypes they were actually testing. The crafts were fairly similar to each other, though Kawasaki were trying different strake patterns or add sponsons, and other things in order to find out how they respond. There was a lot of trial and error involved in to testing back in 1972.

Why the two hull design?
According to Tunstall, Kawasaki went with the two hulls because they were uncertain about who the customer was going to be. The flat hull was much more stable and easy to use; however there was some thought that the V-hull would attract riders interested in competition. Kawasaki never quite knew what they are going to do, especially in rough water. “Man, that thing could curve. The first ride on it, it is worse than a wild horse, but after you spent some time getting used to it, it turned into a lot of fun.”

Apart from the hull design, the two models were the same. In fact, they share the same dimensions, 6-feet, 10 inches long, 24 inches wide and 26 inches high, with a dry weight of 220 lbs and a draft of 4 inches.  Those crafts were only slightly shorter approximately by 2.5 inches and lighter about 25 lbs than the long lived Jet Ski 400. The 1973 models had a real prototype look, with the wooden bulkhead braces and hand-machined hardware and sand cast aluminum parts.

The handlepole was also made of fiberglass, but in two parts which were then riveted together. The first prototypes used –one-piece aluminum tubes but Kawasaki switched to the fiberglass on those first models, which worked pretty well. When Kawasaki moved the Jet Ski production line to Lincoln Nebraska, it switched to SMC (Sheet Molding Compound) and then had a few issues with the handlepoles braking therefore, they pretty much shut down production for almost a year until they solved the problem. The aluminum bars when 30? bend and featured a trigger throttle lever.

The first engine
WSAA and WSAB featured the same two-stroke, twin-cylinder water-cooled engine which was actually a Kawasaki snowmobile engine. Engine displacement was 398cc with a bore and stroke of 65 x 60 mm and a compression ratio of 5.8:1. On the inlet side there was 2-1 intake manifold topped with a Mikuni, 38mm diaphragm type carburetor with a piston-port intake system. On the exhaust side, a water-jacketed head pipe was fit with a stainless steel expansion chamber.

Horsepower was translated in to thrust via a single stage axial flow aluminum jet pump of 121.7mm. The pump intake was fitted with a cast-in bar scoop which design was based on the same theory of latter’s top-loader intake grates. The pump featured initially an aluminum two-blade impeller (only a handful of those prototype skis had two-blade props) which was later replaced with a three-blade one.

Both WSAA and WSAB came standard with a trigger throttle lever like many of today’s personal watercrafts. However the start/stop buttons and the manual choke were situated on the dashboard along with the stainless steel hood latch. The reason behind the awkward position of the start/stop buttons was that at the moment this was the safest way to keep the electric box dry. This was actually one the most important aspects that puzzled Kawasaki engineers back in 1972. Many people assumed it was because so many people started out riding on their knees.

Back in 1973 Kawasaki WSAA and WSAB cost $1995 and both craft were the pioneers of Jet Ski that Kawasaki launched in mass production in 1976 with the JS400.

Specifications
Kawasaki WS-AA and WS-AB
Model:T1C91
Engine
Type: 2T, vertical twin,180? firing piston valve, water-cooled
Displacement (c c ): 398cc
Bore x stroke (mm): 65 x 60
Power (hp/rpm): 26/6.000
Torque (Ft.Lb/rpm): 24/5.000
Compression ratio: 5.8 :1
Fuel induction system: 1 x Mikuni BN38 diaphragm type
Exhaust system: Cast exhaust wet pipe with a 2-1 header
Cooling system: Engine-Exhaust-Open loop system
Fuel consumption (L/h):5.7 @32kph (1.5gal/hr 20mph)
Hull
Type: Modified V, double concave (model WSAA-Flat hull); Deep V, Double concave (model WSAB).
Hull material: Hand laid fiberglass, with gellcoat finish and wood bulkhead bracing.
Deck Material: Fiberglass reinforced SMC
Overall length (mm):  2.140 (84in)
Overall width (mm): 610 (24 in)
Overall height (mm): 640 (26 in)
Weight (kg): 110 (243 lbs)
Pump and drive line
Pump: Axial flow, single stage, 6-vane stator.
Pump diameter (mm): 121.7 (4.8in)
Reduction nozzle diameter (mm): 70
Steering nozzle diameter (mm): 84
Impeller: Aluminum, two blade

The Kawasaki Jet Ski stand-up dream started in 1973 and was sadly ended in 2011 with the last model of the stand up jet ski, the SX-R 800.  From 1973 to 1976 the JS 400 was the only model ski to cruise the waterways. then in 1977 the JS 440 came about with not too much more power but it was a change. 1982-86 the JS 550 and JS 300 made the scene. the 550 for adults and 300 for the children. once 1987 hit, it was just a steam rolling of new types of jet ski's year after year. Below are  the dates and skis that came out within that time period:

1973-1977:     1982-1989:          1990-1995:       1996-2000:           2001-2011:
JS 400             JS 550                   550 SX              550 SX                 SX-R 800
JS 440             JS 300                   650 SX              750 SXi Pro          X-2 800
                        650 X-2                750 SX
                        300 SX                 750 SXi
                        650 SX
                        JB 650 (jetmate)
                        JF 650 TS
« Last Edit: March 06, 2014, 06:12:39 PM by Nigel »
Check out the awesome Jetski XXX Extreme Clean Products Range The 10% discount code is: jetskiclub

Offline Jet Ski Club

  • Administrator
  • *****
  • Posts: 1064
  • Total likes: 31
    • Jet Ski Club
  • I Ride a: I ride anything that starts!
  • My hometown waterway is: Gold Coast, Australia
Re: History of the Jet Ski - stand-up watercraft
« Reply #1 on: March 06, 2014, 01:11:10 PM »
Awesome post!

That settles it then. International Jet Ski Day = August 15th wh
See you on the water for some FUN!
Ph: +61 7 3151 2037
mandy@thejetski.club
jsx17


Offline dallow1

Re: History of the Jet Ski - stand-up watercraft
« Reply #2 on: March 06, 2014, 07:03:20 PM »
i think what nigel is saying here is that he wants a stand up ski!!!!  lovf

Offline Mandy

  • Woo Hoo
  • Member
  • *****
  • Posts: 3771
  • Total likes: 141
  • Fun First!
    • Jet Ski TV
  • I Ride a: I'll ride anything that starts :)
  • My hometown waterway is: Gold Coast, Australia
Re: History of the Jet Ski - stand-up watercraft
« Reply #3 on: March 06, 2014, 07:18:14 PM »
i think what nigel is saying here is that he wants a stand up ski!!!!  lovf

 clp clp clp Two of them!
See you on the water for some FUN!
mandy@jetskitv.tv
Ph: +61 449 077 747
JSX18P

Offline dallow1

Re: History of the Jet Ski - stand-up watercraft
« Reply #4 on: March 06, 2014, 07:19:19 PM »
Maybe Jamie will sell his to old kawa stand ups !!!


Sent from my iPhone using Tapatalk

Offline Sunnycoastjo

Re: History of the Jet Ski - stand-up watercraft
« Reply #5 on: March 07, 2014, 06:26:35 AM »
Nice write up Nigel...
 wh

Let's all get stand ups !! They look fun!

Offline Brian

  • Member
  • *****
  • Posts: 69
  • Total likes: 4
  • "The way to a friends home is never far"
  • I Ride a: 2008 Seadoo GTX
Re: History of the Jet Ski - stand-up watercraft
« Reply #6 on: March 07, 2014, 09:14:37 AM »
Good write up Nigel clp
I was always aware that Kawasaki were first on the scene with Jet-ski's, however is it true that Kawasaki has patented the name "Jetski" and other companies can only refer to their product as PWC"s rjs2

Cheers br

Brian

Offline Nigel

Re: History of the Jet Ski - stand-up watercraft
« Reply #7 on: March 08, 2014, 07:14:23 AM »
The next obvious step was to sit downs..

The first multi-seat JetSki was the 1986 X2, a hybrid two person craft with the novel ability to operate in either stand up or sit down mode. Both styles of machine proved immensely popular and the lakes and seaside towns of America and Europe soon played host to a new form of recreational watercraft offering the performance of a speed boat small enough to be stored in a normal domestic garage and light enough to be easily and launched and recovered or towed behind a family car.

In terms of the evolution of the Jet Ski product, solo skis were increasingly seen as the preserve of the expert or dedicated racing owner while the multi-seat craft became the obvious route for developing the Jet Ski product line for the whole family to use allied to desire for extra storage and creature comforts. Of course being such a popular hobby craft in America, it was obvious that performance and excitement had to be retained by the next range of products but so too was refinement.

Given Kawasaki’s notoriety in the field of three cylinder, two-stroke engines, it was wholly fitting that the following generation utilised water-cooled units with the cylinders running front to back starting initially at 900cc in 1995 and evolving the very next year all the way to the powerful 1100cc ZXI.

Using normal engine technology, there was only so far that two-stroke performance could be pushed in light of noise, exhaust emissions and fuel consumption.

Taking the power unit from the road-going ZX-12R, the team at KHI “marinised” the engine and fitted the fuel injected motor into a race-developed hull christening the impressive 250 horsepower personal water-craft (PWC) the Ultra 250X.

Eventually enlarging the Ultra’s engine to 1500cc released more power and torque but, for many, that was not enough, they demanded more than conventional tuning could deliver. With a turbocharger considered, this technology was eventually rejected in favour of supercharging.

The result was an increase to first 260 horsepower and, more recently, a twin vane Roots style supercharger, delivering a considerable 310 horsepower via the Ultra 310 series.
« Last Edit: March 08, 2014, 07:15:50 AM by Nigel »
Check out the awesome Jetski XXX Extreme Clean Products Range The 10% discount code is: jetskiclub

Offline Nigel

Re: History of the Jet Ski - stand-up watercraft
« Reply #8 on: August 14, 2014, 08:48:19 PM »
International Day of the jet ski.

On August 15, 1971, Clayton Jacobson’s agreement with Bombardier had expired and it was that very day that Kawasaki signed an agreement to license Jacobson’s invention.

Check out the awesome Jetski XXX Extreme Clean Products Range The 10% discount code is: jetskiclub

Offline Brian

  • Member
  • *****
  • Posts: 69
  • Total likes: 4
  • "The way to a friends home is never far"
  • I Ride a: 2008 Seadoo GTX
Re: History of the Jet Ski - stand-up watercraft
« Reply #9 on: August 15, 2014, 09:13:21 AM »
Thanks Nigel  wh

We will eventually rule the waves, so the world can be a better place rjs2

 br
Brian

Offline johno

  • Air Soul for Life🌏
  • Member
  • *****
  • Posts: 223
  • Total likes: 53
  • Jetskiers. Species evolved.
  • I Ride a: Seadoo of course
  • My hometown waterway is: Southern Coral Sea
Re: History of the Jet Ski - stand-up watercraft
« Reply #10 on: August 15, 2014, 02:04:52 PM »
 cl that vid at the top is a classic! had to watch it twice  sk. see the dood going to the beach in one of the coolest classic cars of all time (early '70s el camino ute) jetski in the back, all set for a day on the water, wearing his suit and shiney leather shoes.  ag we've all come along way since then. jetskiers evolve faster than normal humans, thank god the jetskis and fashion sense has been able to keep up with us
See ya at the Gutter Bar
0412 291 126
